Midas

Verified by Experts

Midas M32 Live Digital Mixer

AED 14,990; ~~AED 30,449~~; AED 14,990
Unit price: per

Please hurry! Only 2 left in stock

Quantity:

I agree with

Report Better Price

10 customers are viewing this product

Free shipping on orders over AED99

Warranty Information

Item	Brand	Type	Condition	Warranty period
Piano	All	Upright, Grand	Reconditioned	2 years
	All	Upright, Grand	New	3 years
	All	Upright, Grand	Renewed	2 years
	Steinway	Grand	Renewed	3 years
	All	Digital	New	1 year
	All	Digital	Used	3 months
Guitar	All	Electric, Bass, Semi-Acoustic	Used	3 months
Guitar	All	Electric, Bass, Semi-Acoustic	New	6 months
Guitar Amplifier	All		New	6 months
Violin	All	Silent, Electric	New	3 months
Viola	All	Silent, Electric	New	3 months
Cello	All	Silent, Electric	New	3 months
Bass	All	Silent, Electric	New	3 months
Drums	All	Electric	New	6 months
Keyboard	Steiner		New	6 months - 1 year
Wind Instrument	All	Wind	New	3 months

For More information on warranty please visit: Warranty Information

Description
Reviews
Shipping & Delivery
Warranty
Return & Exchange

Midas M32 Live Digital Mixer

The Midas M32 Live Digital Mixer is a versatile digital console for live performance and studio recording, equipped with 40 input channels, 32 Midas PRO microphone preamplifiers, and 25 mix buses. It offers professional features such as live multitrack recording, AES50 networking, and an array of digital signal processing capabilities.

Product Features

Live performance and studio recording digital console with up to 40 simultaneous input channels
32 award-winning Midas PRO microphone preamplifiers
25 time-aligned and phase-coherent mix buses
AES50 networking allows up to 96 inputs and 96 outputs
32 bi-directional channels of live recording/playback on dual SD/SDHC (cards not included)
Up to 3 hours of 32 channel PCM recording in one session - stored as uncompressed WAV files
High-performance carbon fibre, aluminium and high-impact steel structure
40 bit floating point digital signal processing
8 DCA and 6 mute groups
8 digital signal processing effects engines
25 Midas PRO motor faders
Daylight viewable 7" full colour TFT display screen
32 x 32 channel USB 2.0 audio interface
DAW remote control emulations of Mackie Control and HUI protocols
Optional wireless remote control with Midas Apps for iPhone and iPad
Auto-ranging universal switch-mode power supply

Specifications

Feature	Description
Input Processing Channels	32 Input Channels, 8 Aux Channels, 8 FX Return Channels
Output Processing Channels	16 aux buses, 6 matrices, main LRC
Internal Effects Engines	16 (True Stereo / Mono)
Internal Show Automation	500 structured Cues / 100 Snippets
Internal Total Recall Scenes	100 (including Preamplifiers and Faders)
Signal Processing	40-Bit Floating Point
A/D Conversion	114 dB Dynamic Range (A-weighted*)
D/A Conversion	120 dB Dynamic Range (A-weighted*)
I/O Latency	0.8 ms (Console Input to Output)
Network Latency	1.1 ms (Stage Box In > Console > Stage Box Out)
Midas PRO Series Microphone Preamplifier	32 (XLR)
Talkback Microphone Input	1 (XLR)
RCA Inputs / Outputs	2
XLR Outputs	16
Monitoring Outputs	2 (XLR / ¼" TRS Balanced)
Aux Inputs/Outputs	6 (¼" TRS Balanced)
Phones Output	2 (Stereo, ¼" TRS)
Digital AES/EBU Output	1 (XLR)
AES50 Ports	2 (Klark Teknik SuperMAC)
Expansion Card Interface	32 Channel Audio Input / Output
ULTRANET P-16 Connector	1 (No Power Supplied)
MIDI Inputs / Outputs	1
USB Type A	1 (Audio and Data Import / Export)
USB Type B	1 (for remote control, rear panel)
Ethernet	1 (RJ45, for remote control, rear panel)
Frequency Response	0 dB to -1 dB (20 Hz-20 kHz)
Dynamic Range, Analogue In to Analogue Out	106 dB (22 Hz-22 kHz, unweighted)
A/D Dynamic Range, Output (Typical)	109 dB (22 Hz-22 kHz, unweighted)
Crosstalk Rejection @ 1 kHz, Adjacent Channels	100 dB
Output level, XLR Connectors (Nominal / Maximum)	+4 dBu / +21 dBu
Output Impedance, XLR Connectors (Unbalanced / Balanced)	50 Ω / 50 Ω
Input impedance, TRS Connectors (Unbalanced / Balanced)	20 kΩ / 40 kΩ
Non-Clip Maximum Input Level, TRS Connectors	+21 dBu
Output Level, TRS (Nominal / Maximum)	+4 dBu / +21 dBu
Output Impedance, TRS (Unbalanced / Balanced)	50 Ω / 50 Ω
Phones Output Impedance / Maximum output Level	40 Ω / +21 dBu (Stereo)
Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain	-85 dBu (22 Hz-22 kHz, unweighted)
Residual Noise Level, Out 1-16 XLR Connectors, Muted	-88 dBu (22 Hz-22 kHz, unweighted)
Residual Noise Level, TRS and Monitor out XLR Connector	-83 dBu (22 Hz-22 kHz, unweighted)
Main Screen	7" TFT LCD, 800 x 480 Resolution, 262k Colours
Channel LCD Screen	128 x 64 LCD with RGB Colour Backlight
