PROEL WD12AV2 Active 2-Way Coaxial Stage Monitor

PROEL WD12AV2 Active 2-Way Coaxial Stage Monitor – 12-Inch, 700W Peak

The PROEL WD12AV2 is a professional active 2-way coaxial stage monitor designed for live performances, rehearsals, venues, houses of worship, and sound reinforcement applications. Its 12-inch woofer and 1-inch compression driver provide balanced low-frequency response, clear vocals, and consistent sound coverage across the stage.

With 350 watts of continuous bi-amplified power and 700 watts peak, the WD12AV2 can deliver up to 124 dB SPL. Dedicated Monitor and FOH presets allow the speaker to be adapted for floor-monitor or front-of-house use, while its durable plywood cabinet, low-profile wedge design, and pole socket provide flexible installation options.

Key Features

• Active 2-Way Coaxial Design: Coaxial driver arrangement provides even sound dispersion and consistent monitoring.
• 12-Inch Woofer: Features a 2.5-inch voice coil for strong low-frequency reproduction.
• 1-Inch Compression Driver: Uses a 1.35-inch voice coil for clear high-frequency reproduction.
• 700W Peak Power: Delivers 350 W continuous total amplifier power and 700 W peak output.
• Hybrid Amplification: Uses a 300 W Class-D LF amplifier and 50 W Class-AB HF amplifier with SMPS power supply.
• 124 dB Maximum SPL: Provides strong output for stage-monitor and PA applications.
• 50 Hz–20 kHz Frequency Response: Covers a broad range for vocals, instruments, and playback.
• 80° Coverage: Provides wide and even sound dispersion.
• Monitor & FOH Presets: Two EQ presets optimize response for floor-monitor or front-of-house use.
• Dual Limiter Circuit: Helps protect the loudspeaker during high-level operation.
• Combo Input: Accepts XLR and 1/4-inch jack connections.
• XLR Link Output: Allows the audio signal to be passed to another loudspeaker.
• Ground Lift: Helps reduce unwanted ground-loop noise.
• Plywood Cabinet: Finished with durable black anti-scratch polyurethane paint.
• 36° Monitor Angle: Low-profile wedge shape directs sound toward the performer.
• Pole Socket: Allows use as a conventional PA loudspeaker.
• Recessed Handles: Two side handles support convenient transport.

Specifications

Why Choose the PROEL WD12AV2?

The WD12AV2 combines a compact 12-inch coaxial configuration with 350 W continuous amplification, 124 dB maximum SPL, and dedicated Monitor and FOH EQ modes. Its lightweight plywood cabinet and 15 kg weight make it practical for musicians and live-sound applications where portability and reliable stage monitoring are important.

Versatile 12-Inch Active Monitor for Stage and PA Use

The PROEL WD12AV2 combines a 12-inch woofer, 1-inch compression driver, 700 W peak amplification, 80° coverage, and durable plywood construction in a portable wedge enclosure. It is suitable for vocalists, musicians, bands, rehearsal spaces, venues, houses of worship, and professional sound reinforcement.
